Integral T process thermostats
21/01/2019 / YAWE 0026 Starting up 81
STAT
Read error diagnosis response:
XXXXXXX  X = 0 no error, X = 1, 2, 3 error.
1. Char. = error (Exx).
2. Char. = pump error
0 = OK / 1 = pump 1 / 2 = pump 2 / 3 = both pumps error.
3. Char. = low level error.
4. Char. = overtemperature error.
5. Refrigeration unit error (e.g. pressure switch = PRES).
6. Char. = no external temp. probe (TE FAIL).
7. Char. = error analogue inputs
0 = OK /
1 = current analogue setpoint input < 4 mA /
2 = current analogue actual temp. input < 4 mA /
3 = both current inputs < 4 mA.
RMP_IN_00_XXX
Read a programme segment XXX
(response: e. g. 030.00_010.00 = 30.00 °C and 10 min).
RMP_IN_01
Read the current segment number.
RMP_IN_02
Read the set number of programme runs.
RMP_IN_03
Read the current programme run.
RMP_IN_04
Read the programme to which further instructions apply.
RMP_IN_05
Read which programme is running now (0=none).

 For ”_“ use also ” ” (blank character).
 The equipment response is always in the fixed decimal format ”XXX.XX“ or for
negative values “-XXX.XX” or ”ERR_X“. (RS 485 interface e.g.. ”A015_ XXX.XX” or
”A015_-XXX.XX” or ”A015_ERR_X”).
