17
5.1 Filling, venting and degassing the application
To do so, follow the operating instruction of the LAUDA Integral XT ( chapter 7.6).
5.2 Operation
5.2.1 Switching on
Error when switching on/off
Always switch the flow controller on first
Ensure that the device has been filled with heat transfer
liquid before it is switched on.
Procedure for switching on
1. Set the mains switch of the flow controller to position 1.
2. Set the mains switch of the main device to position 1.
3. Select the soft key “Flow”.
4. Use the “up” and “down” arrow buttons to move the cursor to the “Status” menu item and press
“Enter” or the “right” arrow button to confirm.
5. Use the “up” and “down” arrow buttons to move the cursor to “On” and press “Enter” or the “right”
arrow button to confirm.
If the status “On” has been selected, the valve regulates to the desired flow rate. This setting is
active until you set the status to “Off”. Note that the flow through the flow controller is highest
when the position “Off” is selected.
5.2.2 Setting the target flow rate
Procedure for setting the target flow rate
1. Select the soft key “Flow”.
2. Use the “up” and “down” arrow buttons to move the cursor to the “Target flow rate” menu item and
press “Enter” or the “right” arrow button to confirm.
3. The input field is now above the current value of the target flow rate. Now press “Enter”.
4. Now use the soft keys to enter a value between 0 and 20 L per min and confirm the value with
“Enter”.
Example: Inputting a target value of 7.53 L per min.
Use the soft keys to enter 00753 and confirm by pressing “Enter”.
