5.2.3 Settings for the higher-pressure pump
If your device has a higher-pressure pump, the existing LiBus software connection is detected
and the setting automatically switches from Aux. Pump OFF to Aux. Pump ON . When the
flow controller of the Integral XT is dismantled, the automatic setting described above must be
undone manually on the command remote control unit of the Integral XT.
Procedure for deregistering the flow controller
1. Select the soft key “Menu“.
2. Use the “up” and “down” arrow buttons to move the cursor to the “Pump” menu item and press
“Enter” or the “right” arrow button to confirm.
3. Use the “up” and “down” arrow buttons to move the cursor to the “Aux. Pump ON” menu item and
press “Enter” or the “right” arrow button to deregister the pump of the flow controller.
5.2.4 Setting the control parameters
For flow rate control, the actuating signals are a continuous valve and the pump speed.
The two actuating signals can be parameterised using separate PI controllers.
Procedure for setting the control parameters
1. Select the soft key “Flow”.
2. Use the “up” and “down” arrow buttons to move the cursor to the “Control parameters” menu item
and press “Enter” or the “right” arrow button to confirm.
3. Use the “up” and “down” arrow buttons to move the cursor to the desired control parameter and
press “Enter” to confirm.
4. Now use the soft keys to enter a value between 0 and 10 and confirm the value with “Enter”.
Proportional share, controller valve
Integral share, controller valve
Proportional share, controller pump
Integral share, controller pump
