6. Interface commands
The following interface commands are valid for flow rate control. Input is via the selected
interface on the Integral XT.
6.1 Additional commands for RS 232/485 and Ethernet interface
6.1.1 Write commands
Data specifications to the flow meter:
Command
Meaning
PO_4_25_0_E6
Switch on the flow rate control.
PO_4_25_1_E7
Switch off the flow rate control.
PO_4_24_XX.XX_CS
Specify the target value for the flow rate control.
Setup of the write command PO_4_24_XX.XX_CS
The value CS is a checksum.
The value XX.XX is within the range of 00.00 to 20.00 in the unit L/min
CS depends on the value XX.XX and can be calculated as follows:
All digits before the checksum are shown in decimal and added up. The calculated value is converted
to hexadecimal and the last two digits are added to the command as a checksum.
Example:
Target flow rate value: PO_4_24_XX.XX_CS
With a target flow rate of 12.34 L/min, the calculation is as follows:
‘P’ = 80
D
‘O’ = 79
D
‘_’ = 95
D
.4 = 52
D
‘_’ = 95
D
‘2’ = 50
D
‘4’ = 34
D
‘_’ = 95
D
‘1’ = 49
D
‘2’ = 50
D
‘.’ = 46
D
‘3’ = 51
D
‘4’ = 52
D
‘_’ = 95
D
The sum of “PO_4_24_12.34_” is 923
D
= 39B
H
.
The CS is then the last two digits of the hexadecimal checksum, i.e. 9B
H
.
The following character string must thus be transferred:
PO_4_24_12.34_9B<CR>
