PROFINET-IO (LCBPROFINETIO only)
INSTRUMENT SETUP
-  (default: ): it allows to select the reading/writing of the byte in LITTLE-ENDIAN or BIG-
ENDIAN mode
- : LITTLE ENDIAN
- : BIG ENDIAN
PC/PLC SETUP
The instrument works as device in a Profinet-IO network and features a dual port that allows to
exchange the weight and the main parameters with a Profinet-IO controller. Load the gsdml file
attached to the instrument to the development system and configure the device. Assign a name to the
device (function Assign Device Name) using case letters (a-z), numbers (0-9), minus character (-) and
set at least 1 ms as Profinet's I/O refresh time.
The data exchanged by the instrument are:
Output Data from instrument (reading)
Addresses
Type
Gross weight
0x0000-0x0003
20 byte output
Net weight
0x0004-0x0007
Exchange register R1
0x0008-0x000B
Exchange register R2
0x000C-0x000D
Status Register 1
0x000E-0x000F
Status Register 2
0x0010
Instrument status
0x0011
Execution register
0x0012-0x0013
Digital inputs status
0x0014
2 byte output
Digital outputs status
0x0015
Input Data to instrument (writing)
Addresses
Type
Command Register
0x0000-0x0001
2 byte input
Digital outputs command
0x0002-0x0003
8 byte input
Exchange register W1
0x0004-0x0007
Exchange register W2
0x0008-0x0009



