LAUMAS LCB - Communication Interface

- 2 -
KEY
Function
Keyboard shortcut
Enter in menu/return to the weight displaying
CTRL+M
Confirm or enter in submenu
ENTER
Select figure to be modified or go to previous menu item
LEFT ARROW
Modify selected figure or go to previous menu item
UP ARROW
Select figure to be modified or go to next menu item
RIGHT ARROW
Modify selected figure or go to next menu item
DOWN ARROW
Cancel or return to previous menu
ESC
Into menus LEDs light up in sequence to indicate that it is not displaying a weight.
COMMUNICATION INTERFACE
Data exchanged by the instrument can be input data or output data. For specific information regarding
the communication interface used, see section FIELDBUS.
Output data from instrument (reading)
Abbreviation*
Dimension (byte)
Gross weight
GW
4
Net weight
NW
4
Exchange register R1
R1
4
Exchange register R2
R2
2
Status Register 1
SR1
2
Status Register 2
SR2
1
Instrument status
IS
1
Execution register
EXR
2
Digital inputs status
INS
1
Digital outputs status
OUTS
1
Input data to instrument (writing)
Abbreviation*
Dimension (byte)
Command Register
CMDR
2
Digital outputs command
CMDOUT
2
Exchange register W1
W1
4
Exchange register W2
W2
2
*In the user manual, the abbreviation of the registers will be used instead of the
extended name.
