LAUMAS LCB - Execution Register (Exr); Inputs (Ins) and Outputs (Outs) Status

- 4 -
6
 alarm
19
 alarm
7
 alarm
20
8
 alarm
21
9
22
10
 alarm
23
11
24
Temporary message 
12
EXECUTION REGISTER (EXR)
This register allows you to monitor the progress of a command previously sent to CMDR.
Register contents
Description
Command code sent to CMDR
Command executed correctly
0
No command running
1
Command running
4
Error: the command requires a qualified access
5
Error: non-existent command
0xFFFF
Error: command not executed
It may take several seconds to execute some commands.
INPUTS (INS) AND OUTPUTS (OUTS) STATUS
DIGITAL INPUTS STATUS (INS)
DIGITAL OUTPUTS STATUS (OUTS)
Bit 0
INPUT 1 status
Bit 0
OUTPUT 1 status
Bit 1
INPUT 2 status
Bit 1
OUTPUT 2 status
Bit 2
Bit 2
OUTPUT 3 status
Bit 3
Bit 3
Bit 4
Bit 4
Bit 5
Bit 5
Bit 6
Bit 6
Bit 7
Bit 7
Bit=1: high input; Bit=0: low input
Bit=1: output is closed; Bit=0: output is open
