4. Initial Use
4.1 Connection
1). Turn the ignition off.
Figure 4-1
2). Locate the vehicle’s 16-pin Data Link Connector (DLC). Refer to Chapter
2.4.
3). Plug the diagnostic cable of the tool into the vehicle’s DLC.
Figure 4-2
Notes:
• A plasc DLC cover may be found for some vehicles and you need to remove it
before plugging the diagnosc cable.
• The cable connector is keyed and will only t one way. If you have problems
connecng the cable connector to the DLC, rotate the connector 180
o
and try
again.
