LAUNCH X-431 PROS MINI User Manual
25
Fig. 4-19
On-screen Buttons:
Exit:
Tap to return to the home screen.
Graph:
After selecting, tap it to view the waveform. There are 3 types of
display modes available for data viewing, allowing you to view various types
of parameters in the most suitable way.
 Graph – displays the parameters in waveform graphs.
 Value – this is the default mode which displays the parameters in texts
and shows in list format.
 Combine – this option is mostly used in graph merge status for data
comparison. In this case, different items are marked in different colors.
Record:
Tap to start recording diagnostic data for future playback and

Launch X-431 PROS MINI Specifications

General

RAM	2GB
Storage	16GB
Operating System	Android 7.0
Connectivity	Wi-Fi, Bluetooth
Processor	Quad-core
Battery	3000 mAh
Camera	5MP rear
Supported Protocols	OBDII, CAN
Vehicle Coverage	Over 100 brands
