LAVAZZA CLASSY PLUS - COMPONENTS AND CONTROLS; Machine Components Overview

5
EN
Water tank cover
Water tank
Cup/milk frothing
jug rest grid
Used capsules drawer
Milk frothing jug
User interface
Power cord
Chrome lever
Drip tray drawer
COMPONENTS AND CONTROLS
