LDG AT-200Pro - Specifications; An important word about power levels; IMPORTANT SAFETY WARNING

4
Specifications
•
0 to 250 watts SSB and CW peak power, 200 watts continuous (100 watts on 6M)
• Easy to read LED bargraph display for RF power, SWR and status
• 16,000 "3-D" memories for instantaneous band changing
• Two position antenna switch with memories for four antennas on each position
• Tuning time: 0.5 to 6 seconds full tune, < 0.2 second memory tune
• Built in frequency counter for memory operation
• Frequency coverage: 1.8 to 54.0 MHz.
• Tunes 6 to 1000 ohm loads (16 to 150 ohms on 6M), 6 to 4000 ohms with
optional 4:1 Balun (LDG RBA-1)
• For Dipoles, Verticals, Vs, Beams or and Coax Fed Antenna
• Optional external Balun allows tuning of random length, long wire or ladder line
fed antennas
• Optional interfaces for Icom, Alinco, Kenwood and Yaesu available
• Power requirements: 11 to 15 volts DC at 750 mA max during tuning
• Enclosure: 9 x 7 x 2 inches
• Weight: 2 pound
An important word about power levels
The AT-200Pro is rated at 250 watts maximum power input at most. Many ham transmitters and
transceivers, and virtually all amplifiers, output well over 250 watts. Power levels significantly
exceeding specifications will definitely damage or destroy your AT-200Pro. If your tuner fails
during overload, it could damage your transmitter or transceiver. Be sure to observe the specified
power limitations.
IMPORTANT SAFETY WARNING
Never install antennas over or near power lines. You can be
seriously injured or killed if an
y
part of the antenna, support
or transmission line touches a power line. Alwa
y
s follow this
antenna safet
y
rule: the distance to the nearest power line
should be at least twice the len
g
th of the lon
g
est antenna or
su
pp
ort dimension.
