Features
• Automatically matches antennas from 6 – 800 ohms impedance, or a 10:1 SWR
• Very low current consumption: 300 mA during turning, less than one microamp in standby, or can
be turned off completely. No cooling fan needed! Your AT-897 is ideal for battery-powered
operations.
• Uses latching relays, to retain tuned setting indefinitely even when power is completely removed
• Powered by the FT-897 through the CAT cable (provided); no external power source required
• CAT port access provided
• Tunes in less than 8 seconds, usually around 4 seconds
Specifications
• Microprocessor controlled, switched L tuning network
• Antenna impedance: 6 to 800 Ohms (Approximately up to 10:1 SWR)
• Continuous coverage 1.8 to 54 MHz
• 200 fast memories
• Latching Relays hold tuned setting indefinitely, even when power is removed
• Tunes nearly any coax fed or unbalanced input antenna. Use optional Balun for long wires or
balanced input antennas
• Mounts directly on the side of the Yaesu FT-897, provides side feet attachment
• Dual function tune control button – Tune or Bypass
• Power rating HF: 0.1 to 100 Watts
• Provides CAT port access
• Tuning time: 1 to 8 seconds, 4 average
• Power requirements: 10 to 15 volts DC @ 300 mA during tune
• Operating voltage supplied via the FT-897 CAT/Linear Port (cable supplied with tuner)
• Enclosure sizes: 11.5” x 3.25” x 1.5”
• Weight: 2 pounds
