7
G6A Low Signal Relay
G
6
A
●High-frequency Characteristics
• Measurement Conditions
Note: The high-frequency characteristics data were measured using a dedicated circuit board and actual values will vary depending on the usage conditions. Check
the characteristics of the actual equipment being used.
*1. The tests were conducted at an ambient temperature of 23°C.
*2. High-frequency characteristics depend on the PCB to which the Relay is mounted. Always check these characteristics, including durability, in the actual machine
before use.
●Time distribution of Operating and Release/Set and Reset *1
G6A-274P G6AK-274P
●Bounce Time distribution of Operating and Release/Set and Reset
*1
G6A-274P G6AK-274P
Sample: G6A-274P 5 VDC
Number of Relays: 50 pcs
100
80
60
40
20
0
1 2 3 4
Time (ms)
Number of contacts
Must operate time
Must release time
Set time
Reset time
Sample: G6AK-274P 5 VDC
Number of Relays: 50 pcs
60
40
20
0
1 2 3 4
Time (ms)
Number of contacts
Operating bounce time
Release bounce time
Sample: G6A-274P 5 VDC
Number of Relays: 50 pcs
60
40
20
0
0.5 1.0 1.5
Time (ms)
Number of contacts
Set bounce time
Reset bounce time
Sample: G6AK-274P 5 VDC
Number of Relays: 50 pcs
80
60
40
20
0
0.5 1.0
Number of contacts
Time (ms)
●High-frequency Characteristics
(Isolation) *1, *2
(Average value (initial))
●High-frequency Characteristics
(Insertion Loss) *1, *2
(Average value (initial))
●High-frequency Characteristics
(Return Loss, V.SWR) *1, *2
(Average value (initial))
Terminals which were not being measured were terminated with 50 Ω.
Measuring impedance: 50 Ω
HR 8501
Transmission
reflection
test-set
Terminator
50Ω
G6A-274P
HR 8505A
Network
analyzer
HP
8501A
Storage
normalizer
RF
R
A
B
0
20
40
60
80
100
0 20 40 60 80 100
Frequency (MHz)
Isolation (dB)
Sample: G6A-274P
Number of Relays: 10 pcs
0
0.5
1.0
1.5
0 100 200 300 400 500 600
Frequency (MHz)
Sample: G6A-274P
Number of Relays: 10 pcs
Insertion loss (dB)
0
5
10
15
20
25
0 200 400 600 800 1,000
Frequency (MHz)
V.SWR
2.0
1.5
1.0
Sample: G6A-274P
Number of Relays: 10 pcs
V.SWR
Return loss
Return loss (dB)
