5-14 Performance Verification Rev. D
This test measures the DC Accuracy of the absolute voltage measurements at 0V
offset setting. It requires a DC source with a voltage range of 0 V to 20 V
adjustable in steps of no more than 15 mV, and a calibrated DMM that can
measure voltage to 0.1 %. Measurements are made using voltage values applied
by the external voltage reference source, measured by the DMM, and in the
oscilloscope using the parameters Std voltage.
For each known input voltage, the deviation is checked against the tolerance.
Specification & Test limits
±
(0.015 x | Vm + Voffset | + 0.015 x | Voffset| + 0.01 x FS + 1mV)
Vm
[volts] = voltage reading [volts]
FS [volts] = 8[div] x sensitivity [volt/div]
Voffset [volts] = setting offset voltage [volts]
Procedure
!
Recall
xxxP018.PNL
or configure the DSO:
Panel Setups :
Recall FROM DEFAULT SETUP
Channels Trace ON
Channel 1, Channel 2, Channel 3 & Channel 4
Input Coupling :
DC 1M
Ω
ΩΩ
Ω
on all 4 Channels
Input offset :
0.0 mV
on all 4 Channels
Input gain : from
2mV/div to 1 V/div and 5V/div.
(see Table 6) on
all 4 Ch
Trigger setup :
Edge
Trigger on :
line
Slope line :
Positive
Mode :
Auto
Time base :
2 msec/div
.
Channel use :
4
Record up to :
25 k
Channels Trace OFF
Channel 1, Channel 2, Channel 3 & Channel 4
ANALYSIS CONTROL
Trace ON :
A, B, C & D
MATH TOOLS
For Math :
Use at most 5000 points
Redefine A, B, C, D
Channel 1, Channel 2, Channel 3 & Channel 4
Use Math ? :
Yes
Math Type :
Average
Avg. Type :
Summed
For :
100 sweeps
WAVE PILOT :
MEASURE
Mode :
Custom
Statistics :
off
Change parameters
On line 1 :
Measure
mean of A
To Next Page
