3-8 Specifications
3.27 Extended Measure Tools
cycle median first point
∆time@level, % and volts
last point
∆time @level from trigger
number of points
∆time from clock to data + (setup
time)
median
∆time from clock to data - (hold time)
rise @ level, % and volts
fall @ level, % and volts std. Deviation
duration
3.28 WaveAnalyzer
Includes the Extended Math and Measure Tools as well as expanded capabilities for
performing FFT's, averaging, histograms, and histogram paramters.
3.29 WaveAnalyzer Tools (Standard)
Histograms with 18 histogram parameters up to 2 billion events
Summed averaging to one million sweeps
FFT capability expands the basic FFT to include:
FFT power averaging
FFT power density – real and imaginary
FFT on all acquisition points up to 25 Mpts
With Waveanalyzer FFT you get maximum resolution at wide frequency spans.
3.30 Other Application Solutions Available
Jitter and Timing Analysis (JTA)
Digital Filter Package (DFP)
PowerMeasure Analysis (PMA1)
Communications Mask Testing (MT01/MT02)
Polymask Mask Testing (PMSK)
Advanced Optical Recording Measurements (AORM) for LT37X scopes
Disk Drive Measurements (DDM)
PRML Analysis (PRML)
3.31 Free Software Utilities
ScopeExplorer: Easy-to-use utility that provides a simple but powerful way to control your
scope remotely over RS-232-C, GPIB, or Ethernet.
ActiveDSO: Active X controls for flexible Windows applications programming with remote
control.
MaskMaker: Create your tolerance mask offline with this graphic tool.
DSO Filter: Specify a set of filter coefficients offline and load them into the scope.
