LeCroy Waverunner2 LT584M

7-18 Mechanical Parts & Removal
LT344/224 FRONT PANEL ASSY
Item IWATSU Part Number Quantity Description
1 KCM140911 1.0 BEZEL FND14 UL-1
2 KGM029711 1.0 FND14 KEY PUBBER UL-I
3 MZT007871 1.0 GASKET UC-3E0564 UL-I
4 KPA219011 1.0 LT344 CONTROL PANEL UL-I
5 KCM141021 7.0 KNOBE-D9 UL-I
6 KCM141121 4.0 KNOBE-D12 UL-I
7 21302-5613 1.0 PANEL & KEY BOARD
See Fig [H7]
1 to 7 21302-5678 1.0 LTxx4 FRONT PANEL(4CH)
See Fig [H6]
LT342/322 FRONT PANEL ASSY
Item IWATSU Part Number Quantity Description
1 KCM143211 1.0 BEZEL FND12 UL-1
2 KGM029711 1.0 FND14 KEY PUBBER UL-I
3 MZT007871 1.0 GASKET UC-3E0564 UL-I
4 KPA219111 1.0 LT342 CONTROL PANEL UL-I
5 KCM141021 7.0 KNOBE-D9 UL-I
6 KCM141121 4.0 KNOBE-D12 UL-I
7 21302-5613 1.0 PANEL & KEY BOARD
See Fig [H7]
1 to 7 21302-5679 1.0 LTxx2 FRONT PANEL(2CH)
See Fig [H6]
