LeCroy Waverunner2 Series

7-6 Mechanical Parts & Removal
Printer Parts
Item IWATSU Part Number Quantity Description
1 MKB130062 4.0 Screw KB(+)3X6S(NIP)
2 DZB992361 1.0 PRINTER FTP-642MCL001
3 KHB189311 1.0 PRINTER POWER CABLE UL-I
4 KHB189611 1.0 PRINTER HEAD CABLE UL-I
5 AHB202811 1.0 FFC-26P-L140-P1/CPU
6 KCM141211 1.0 PRINTER CASE UL-I
7 MFA001471 1.0 TL-304-1
8 KBA785511 1.0 PRINTER BASE UNIT
9 MSQ901661 3.0 Screw TT2(+)3X8S
10 KBA786211 1.0 CENTER FRAME
11 MKB130062 2.0 Screw KB(+)3X6S(NIP)
12 MSQ903531 3.0 Screw S-tight KB(+)2.5X6S
13 MKB130062 4.0 Screw KB(+)3X6S(NIP)
14 MHK000961 1.0 BAND CV-70/YJ-80
15 KCM142121 1.0 TKM KEYTOP B- GR UL-I
2 to 15 21302-5681 1.0 LT PRINTER UNIT(GP02)
See Fig [C3, C4]
