Quick Start Summary
The following checklist includes the minimum required settings to start us-
ing the receiver.
• Install either a battery sled or camera slot adapter kit (see pages 5-6).
• Connect power to the receiver (see page 6-7).
• Set the DIVMODE for single or dual channel operation (see pages 8-9).
• Set the COMPAT (compatibility) mode for the transmitters to be used
(see pages 8-9).
• Find clear operating frequencies for one or both receivers (see page
10).
• Set transmitters on the matching frequencies (see transmitter manual).
• Verify transmitters are set to the same compatibility mode as the re-
ceiver (see transmitter manual).
• Adjust transmitter input gain to match voice level and mic position (see
transmitter manual).
• Adjust receiver output level as needed for the camera or mixer input
level desired (see pages 8-9).
IMPORTANT:
FREQ.
WARNING
Performance will be degraded if
Receiver 2 is set 4.2 to 4.8 MHz higher
than Receiver 1. The LCD will also flash
this message periodically.
