Battery Adapters
Battery sled adapters configure the receiver for standalone use or to pro-
vide battery backup power. Several options are available:
• SRBATTSLEDTOP
• SRBATTSLEDBOTTOM
• SR9VBP (inserts into the SLED adapters)
SRBATTSLEDTOP
SRBATTSLEDBOTTOM
The battery sled adapters accept L and M type video camera rechargeable
batteries and the optional SR9VBP 9 volt battery case.
L or M type video
camera batteries
mount directly onto
the battery sled
SR9VBP
battery
case for
two 9 volt
batteries
The battery sled adapters do not include charging circuitry. Batteries must
be charged with their respective chargers. The adapters include an inte-
gral circuit that automatically selects between the battery and the external
source, whichever delivers the highest voltage.
