LeeBoy 8500 - Page 55

ITEM
NO.
QTY.
PART NO. DESCRIPTION
851626 CONVEYOR, ASSY. COMPLETE
851627 BED ASSY. 8500 CONVEYOR
1 851111 CAPSCREW, 1/2"x2" 2
2 851112 WASHER, COUNTER SUNK 1/2 2
3 851473 SPROCKET, OUTER DRIVE 2
4 851483 CONVEYOR MOUNTING PLATE WITH BEARING 2
5 851474 SPROCKET, OUTER DR. C-188 2
6 850030 SPROCKET, INNER DRIVE C-188 2
7 851130 BEARING, AUGER, AXLE, IDLER 20
8 851116 DRIVE SHAFT, CONVEYOR 2
9 850040 SNAP RING, CONVEYOR DRIVE SHAFT 2
10 102-405-1A CAPSCREW, 1/2"x1"
A/R
11 118-5 WASHER, LOCK 1/2" 2
12 851117A CONVEYOR CHAIN, ASSEMBLY
A/R
13 850070A LINK, MASTER 4
14 850080 BLOCK LINK
A/R
15 850090 LINK PIN, CONVEYOR CHAIN
A/R
16 850100 COTTER PIN, CONVEYOR CHAIN
A/R
17 850215A HALF LINK, CONVEYOR CHAIN
A/R
18 851118A BAR, CONVEYOR FLIGHT BAR (QUICK CHANGE)
A/R
19 851118-2 TAB, WELDMENT (QUICK CHANGE )
A/R
20 851118-1 PIN, ROLL PIN (3/8"x2") 2
21 260130 HYD. MOTOR, CONVEYOR MAIN 2
21A 860014 SEAL KIT, HYD. MOTOR
A/R
22 851120 SPROCKET, CONVEYOR DRIVE MOTOR 2
23 851121 CHAIN, CONVEYOR DRIVE 2
24 800282 CAPSCREW, 5/8"x1 1/4"
A/R
25 118-7 LOCKWASHER, 5/8"
A/R
26 850038 L DEFLECTOR, LEFT SIDE (Specify High Deck or Low Deck)
A/R
26 850038 R DEFLECTOR, RIGHT SIDE (Specify High Deck or Low Deck) 4
27 850040 SNAP RING, CONVEYOR DRIVE SHAFT 4
28 850120 IDLER, CONVEYOR CHAIN FRONT 4
29 851123 TUBE ASSY. CONVEYOR FRONT CHAIN GUIDE 2
29A 851653 CAPSCREW, 5/8”x2” FLAT SOCKET HEAD
30 851124 SHAFT, CONVEYOR FRONT IDLER 2
31 850162 ROLLER, CONVEYOR CHAIN GUIDE 4
32 851651 TUBE ASSY, CONVEYOR REAR DRIVE 2
32A 851652 CAPSCREW, 5/8”x1” FLAT SOCKET HEAD
33 851128 SCRAPER, CONVEYOR 2
34 851129 STOP RUBBER, (SCRAPER) 2
35 850170 SET SCREW 4
CONVEYOR DRIVE ASSEMBLY
5
