LeeBoy 8500 - Page 63

ITEM
NO.
QTY.
PART NO. DESCRIPTION
1 260130 HYDRAULIC MOTOR 2
2 851148 BOLT, CONVEYOR DRIVE CHAIN ADJUSTER 4
3 851149 MOUNT, CONVEYOR DRIVE MOTOR 2
4 851121 CHAIN, CONVEYOR DRIVE (#80) 2
5 851120 SPROCKET, CONVEYOR DRIVE MOTOR 2
6 851111 CAP SCREW, 1/2"-13 x2"HEX HEAD 8
7 116-5 NUT, 1/2"-13 HEX 8
8 851151L CHAINGUARD, CONVEYOR L.H. DRIVE 1
8A 851151R CHAINGUARD, CONVEYOR R.H. DRIVE 1
9 930039 COTTER PIN, 3/16" X 2" LONG 4
10 118-3 WASHER, 3/8" LOCK 6
11 102-203-1A CAP SCREW, 3/8"-16 x 3/4"HEX HEAD 6
12 851436 HYD. CYL., SCREED LIFT (1000C / 8000C / 8500) 2
13 118-10 WASHER, 1" LOCK 2
14 100-913-1A CAP SCREW, 1"-14x3 GR. 8 HEX HEAD 2
15 142-10 LOCK NUT, 1"-14 HEX 2
16 100-915-1A CAP SCREW, 1'-14x3 1/2", GR.8 HEX HEAD 2
17 851152 PLATE, CUTOFF CYLINDER MOUNT 2
18 102-607-1A CAP SCREW, 5/8"-11x1 1/2" HEX HEAD 6
19 118-7 WASHER, 5/8" LOCK 6
20 240030 PIN, HYDRAULIC CYLINDER 2
21 910170 HYD. CYL., CUTOFF 2
22 851153 CUT-OFF LEFT SIDE 1
23 851154 CUT-OFF RIGHT SIDE 1
24 102-5-1A CAP SCREW, 1/4"-20x 1" HEX HEAD 2
25 118-1 WASHER, 1/4" LOCK 2
26 860036 WASHER, FENDER (1/4 2
27 102-114-1A CAP SCREW, 5/16"-18 x 3 1/2" 4
28 119-2 WASHER, 5/16" FLAT 4
29 118-2 WASHER, 5/16" LOCK 4
30 116-2 NUT, 5/16"-18 HEX 4
31 850001 MANIFOLD ASSEMBLY, AUGERS AND 2- SPEED 1
32 850005 COIL, 12V AUTO AUGER (WATERMAN)
A/R
33 851237A COIL, WITH DIODE, 12 V SINGLE TERMINAL (AUGERS& 2 SPEED)
A/R
34 851237 COIL, 12 V TWIN TERMINAL (AUGERS& 2 SPEED)
A/R
NOTE: WHEN ORDERING COILS ALWAYS RECORD MANIFOLD BLOCK
NUMBER: IE: 8500-01-A OR 8500-01-F
CONVEYOR DRIVE CUTOFF,
SCREED LIFT CYLINDERS
13
