ITEM
NO.
QTY.
PART NO. DESCRIPTION
1 851177 SCREED, ASSEMBLY (STYLE C) 1
1 851178 SCREED ASSEMBLY (STYLE D) 1
2 851179 BUSHING, SCREED EXTENSION (3" LONG) 1
3 851180 GUARD, HOUSING SPECIFY (L/H OR R/H) 1
4 851181L EXTENSION, UPPER, LEFT SIDE 1
4A 851181R EXTENSION, UPPER, RIGHT SIDE 1
5 851182L WEAR PLATE, L.H. SCREED EXT. (C & D SCREED) 1
5A 851182R WEAR PLATE, R.H. SCREED EXT. (C & D SCREED) 1
6 851183 COUPLING, MALE 1
7 851184 ADJUSTING SCREW, SCREED EXTENSION 2
8 851185 RECEIVER NUT, SCREED EXTENSION SCREW 2
9 870030 BEARING, SCREED FLIGHT SCREW 2
10 851186 SPACER 1
11 116-8 NUT, HEX 3/4" 1
12 870279 CAPSCREW, SOCKET HEAD SHOULDER 1
13 143-3 LOCKNUT, 3/8"-16 1
14 102-309-1A CAPSCREW, 7/16"x2" HEX HEAD 1
15 119-4 WASHER, FLAT, 7/16" 1
16 851256 SNAPRING 2
17 851188 SHAFT, EXTENSION 2
18 851179 BUSHING, SCREED EXTENSION (3" LONG) 2
19 851190 SLIDE, INNER EXTENSION 1
20 100-408-1 CAPSCREW, 1/2"x20x1 1/2" HEX HEAD 2
21 118-5 WASHER, 1/2" LOCK 2
22 119-5 WASHER, 1/2" FLAT 2
23 851191 HYD. CYL., SCREED EXT. (L.H.) 1
23 851192 HYD. CYL., SCREED EXTENSION (R.H.) 1
24 860048 CAPSCREW, 7/16"x2" HEX HEAD 2
25 210060 PIN, CYLINDER 2
26 118-4 WASHER, 5/8" FLAT 2
27 870220 MOTOR, HYDRAULIC SCREED VIBRATOR 1
28 102-606-1A CAPSCREW, 5/8"-11x1 1/4" HEX HEAD 2
29 118-7 WASHER, 5/8" LOCK 2
30 119-7 WASHER, 5/8" FLAT 2
31 870232 VIBRATOR, SCREED 1
32 870172 TURN BUCKLE, CROWN & VALLEY (FRONT) 1
33 870190 CHAIN, CROWN & VALLEY #40 1
34 870182 TURN BUCKLE, CROWN & VALLEY (REAR) 1
35 851195 HANDLE, CRANK 1
36 102-607-1A CAPSCREW, 5/8"x 1 1/2" 2
37 118-7 WASHER, 5/8" LOCK 2
38 119-7 WASHER, 5/8" FLAT 2
39 851299 GUIDE, EXTENSION LOWER, (WELDMENT) 2
40 851298 GUIDE, EXTENSION TOP 1
41 102-406-1A CAPSCREW, 1/2"x 1 1/4" 2
42 118-5 WASHER, LOCK 1/2" 2
43 119-7 WASHER, FLAT, 1/2" 2
44 851196 PIN, SCREED EXTENSION HINGE 1
45 119-4 WASHER, FLAT, 7/16" 2
46 116-5 NUT, 7/16" 2
EXPANDABLE SCREED ASSEMBLY
(PART I)
39
