ITEM
NO.
PART NO. DESCRIPTION
1 851206 EXTENSION, SCREED ARM 1
2 851207 REAR, SCREED ARM, (RIGHT) 1
3 851208 REAR, SCREED ARM, (LEFT NOT SHOWN) 1
4 851209 MOUNT, PIVOT 1
*5 851518 SCREW, ELECTRIC (6"INCH) SERIAL #1712 AND UP 2
6 851210 EARS, PIVOT 2
7 851211 END, ROD END OF SCREW 1
8 851212 END, MOTOR END OF SCREED 1
9 851213 CLEVIS, 3/16" X 1/4" 1
*10 851520 CABLE, HEIGHT LOCATOR 3/16x90 WITH 5”STROKE SERIAL#1712 AND UP 1
11 851215 DECAL, HEIGHT 1
12 102-411-1A CAPSCREW, 1"x 2 1/2" 1
13 116-10 NUT, LOCK 1 " -8 HEX 1
14 102-611-1A CAPSCREW, 5/8" - 11 x 2 1/2” 3
15 116-7 NUT, LOCK 5/8 " 3
16 851134 CAPSCREW, 3/8" -16 x 3/4" 2
17 119-3 WASHER, FENDER 3/8" 2
18 102-9-1A CAPSCREW, 1/4"x 2" 1
19 116-1 NUT, LOCK 1/4" 1
20 102-408-1A CAPSCREW, 1/2" -13 x 1 3/4" 2
21 115-5-A NUT, LOCK 1/2" 2
22 851221 BRACKET, GRADE CONTROL 1
*23 851001A MOUNTING PLATE 6” ELECTRIC SCREW SERIAL # 1712 AND UP
NOTE:
#5 870302 ELECTRIC SCREW (4”)
#10 851214 CABLE, HEIGHT LOCATOR 3/16x90 WITH 3” STROKE
#23 851001 MOUNTING PLATE 4” ELECTRIC SCREW USED ON
PAVERS WITH SERIAL # BELOW 1711
SCREED ARM ASSEMBLY WITH
CENTER TOE POINT
