This documentation applies to the SM2 and SM4 Vector frequency inverter, and contains important
technical data and describes installation, operation, and commissioning.
These instructions are only valid for SM2 and SM4 Vector frequency inverters with software rev 20
(see drive nameplate).
Please read the instructions before commissioning.
CA BD
Type:
174621.00
Id-No: 00000000
INPUT:
3~ (3/PE)
400/480 V
2.9/2.5 A
50-60 HZ
OUTPUT:
3~ (3/PE)
0 - 400/460 V
2.4/2.1 A
0.75 KW/1HP
0 - 500 HZ
For detailed information
refer to instruction
Manual: SV06
Made in USA
Inverter
SM2 Vector
V0115
2
About these instructions
A
Certications
C
Input Ratings
B
Type
D
Output Ratings
Scope of delivery Important
• 1 SM2 or SM4 Vector inverter
with EPM installed
(see Section 4.4)
• 1 Operating Instructions
After receipt of the delivery, check immediately whether the
items delivered match the accompanying papers. LEESON does
not accept any liability for deciencies claimed subsequently.
Claim
• visible transport damage immediately to the forwarder.
• visible deciencies / incompleteness immediately to your
LEESON representative.
