Appendix A
A.1 Permissable Cable Lengths
The table herein lists the permissable cable lengths for use with an SM Flux Vector inverter with an
internal EMC lter.
NOTE
This table is intended as a reference guideline only; application results may
vary. The values in this table are based on testing with commonly available
low-capacitance shielded cable and commonly available AC induction motors.
Testing is conducted at worst case speeds and loads.
Maximum Permissible Cable Lengths (Meters) for SM Flux Vector Models
with Internal EMC Filters
Mains Model 4 kHz Carrier
(P166 = 0)
6 kHz Carrier
(P166 = 1)
8 kHz Carrier
(P166 = 2)
10 kHz Carrier
(P166 = 3)
Class
A
Class
B
Class
A
Class
B
Class
A
Class
B
Class
A
Class
B
240 V, 1-phase
(2/PE)
ESV251GG2SFG 38 12 35 10 33 5 30 N/A
ESV371GG2SFG 38 12 35 10 33 5 30 N/A
ESV751GG2SFG 38 12 35 10 33 5 30 N/A
ESV112GG2SFG 38 12 35 10 33 5 30 N/A
ESV152GG2SFG 38 12 35 10 33 5 30 N/A
ESV222GG2SFG 38 12 35 10 33 5 30 N/A
400/480 V,3-phase
(3/PE)
ESV371GG4TFG 30 4 25 2 20 N/A 10 N/A
ESV751GG4TFG 30 4 25 2 20 N/A 10 N/A
ESV112GG4TFG 30 4 25 2 20 N/A 10 N/A
ESV152GG4TFG 30 4 25 2 20 N/A 10 N/A
ESV222GG4TFG 30 4 25 2 20 N/A 10 N/A
ESV302GG4TFG 30 4 25 2 20 N/A 10 N/A
ESV402GG4TFG 54 5 48 3 42 2 N/A N/A
ESV552GG4TFG 54 5 48 3 42 2 N/A N/A
ESV752GG4TFG 54 5 48 3 42 2 N/A N/A
NOTE: The “GG” and “G” symbols are place holders in the Model part number that contain different
information depending on the specic conguration of the model.
