45
Commissioning
Code Possible Settings
IMPORTANT
No. Name Default Selection
P405
Current Network
Fault
0 No Fault
1 F.nF1 Netldle Mode
2 F.nF2 Loss of Ethernet I/O connection
3 F.nF3 Network Fault
4 F.nF4 Explicit Message Timeout
5 F.nF5 Overall Network Timeout
6 F.nF6 Overall Explicit Timeout
7 F.nF7 Overall I/O Message Timeout
P406
Proprietary
Manufacturer specic
P407P499
Module Specic Parameters Refer to the Communications
Reference Guide specic to the
network or I/O module installed.
4.5.7 Diagnostic Parameters
Code
Display Range
(READ ONLY)
IMPORTANT
No. Name
P500
Fault History Displays the last 8 faults
Format: n.xxx
where: n = 1..8;
1 is the newest fault
xxx = fault message (without the
F.)
see Section 5.3
P501
Software version Format: x.yz
P502
Drive ID A ashing display indicates that the Drive ID
stored in the EPM does not match the drive
model it is plugged into.
P503
Internal Code Alternating Display: xxx-; -yy
P505
DC Bus Voltage 0 {VDC} 1500
P506
Motor Voltage 0 {VAC} 1000
P507
Load 0 {%} 255 Motor load as % of drive’s output current rating.
See section 2.2.
P508
Motor Current 0.0 {A} 1000 Actual motor current
P509
Torque 0 {%} 500 Torque as % of motor rated torque
(vector mode only)
P510
kW 0.00 {kW} 650.0
P511
kWh 0.0 {kWh} 9999999 Alternating display: xxx-; yyyy when value
exceeds 9999
