Code Possible Settings
IMPORTANT
No. Name Default Selection
P154
TB-30 Scaling:
Torque
100 10 {%} 1000 If P150 = 5 or 6, sets the Torque (as
a percent of motor rated torque) at
which output equals 10 VDC
P155
TB-30 Scaling:
Power (kW)
1.0 0.1 {kW} 200.0 If P150 = 7 or 8, sets the power at
which output equals 10 VDC
P156
Analog Inputs
Conī°guration
0 TB5: (0 - 10 VDC);
TB25: (4-20mA)
1 TB5: (0 - 5 VDC);
TB25: (4-20mA)
2 TB5: (2 - 10 VDC);
TB25: (4-20mA)
3 TB5: (-10 - +10 VDC);
TB25: (4-20mA)
Available on special option module only
4 TB5: (0 - 10 VDC);
TB25: (0-20mA)
5 TB5: (0 - 5 VDC);
TB25: (0-20mA)
6 TB5: (2 - 10 VDC);
TB25: (0-20mA)
7 TB5: (-10 - +10 VDC);
TB25: (0-20mA)
Available on special option module only
P157
TB5 (0 - 10
VDC) Analog
Input Monitoring
Action
0 No Action Selects the reaction to a loss of the
0-10 V signal at TB5
1 P157 < P158 - Trip Fault F_FAU
2 P157 < P158 - Run Preset #8
3 P157< P158 - Run Preset
Seq. #16
Minimum time above/below
Monitoring Level (P158) before
triggering action is 500ms.
4 P157 > P158 - Trip Fault F_FAU
5 P157 > P158 - Run Preset *8
6 P157 > P158 - Run Preset
Seq. #16
P158
TB5 (0-10V)
Analog Input
Monitoring Level
(ML)
0.0 -10.0 {VDC} 10.0
P159
0-10V Analog
Input Deadband
0.0 0 {VDC} 10.0 Not active if [-10 to +10 VDC] option
is selected.
