42
Commissioning
Code Possible Settings
IMPORTANT
No. Name Default Selection
P310
(1)
Motor Stator
Resistance
0.00 0.00 {} 64.00 Will be automatically
programmed by P399
Changing these settings can
adversely affect performance.
Contact factory technical support
prior to changing
P311
(1)
Motor Stator
Inductance
0.0 0.0 {mH} 2000
P315
Dead Time
Compensation
Factor
0.0 -50.0 {%} +50.0 • Adjust dead time correction from
internal default
• Takes effect when P399 = 3.
P330
Torque Limit 100 0 {%} 400 When P300 = 5, sets the maximum
output torque.
P331
Preset Torque
Setpoint #1
100 0 {%} 400 TB-13A activated; P121 = 3 and
P300 = 5
P332
Preset Torque
Setpoint #2
100 0 {%} 400 TB-13B activated; P122 = 3 and
P300 = 5
P333
Preset Torque
Setpoint #3
100 0 {%} 400 TB-13C activated; P123 = 3 and
P300 = 5
P334
(2)
Preset Torque
Setpoint #4
100 0 {%} 400 TB-13D activated; P124 = 3 and
P300 = 5
P340
(1)
Current Loop P
Gain
0.25 0.00 16.0
Changing these settings can
adversely affect performance.
Contact factory technical support
prior to changing.
P341
(1)
Current Loop I
Gain
65 12 {ms} 9990
P342
(1)
Speed Loop
Adjustment
0.0 0.0 {%} 20.0
P343
Slip
Compensation
Response Filter
99 90 {ms} 9999 Low pass lter time constant for
varying the slip compensation
response to changes in the motor
current.
(1) Any changes to this parameter will not take effect until the drive is stopped
(2) Parameter applicable to models 15HP (11kW) and higher.
