Code Possible Settings
IMPORTANT
No. Name Default Selection
P706
Sequencer:
Action after
Stop/Start
transition or
Fault Restart
0
0 Restart at beginning of
sequence
Pointed by TB13x
1 Restart at beginning of current
seg
2 Start at beginning of prior
segment
3 Start at beginning of next
segment
P707
Sequencer:
Number of cycles
1
1 65535 1 = single scan; 65535 = continuous
loop
P708
Sequencer: Time
units/scaling
0
0 0.1 {sec} 6553.5 Setup units/scaling for all
sequencer time related parameters
1 1 {sec} 65535
2 1 {min} 65535
NOTE:
P708 rescales the following sequencer related parameters:
- Segment Times in current step: P712, P717, P722, P727, P732,
P737, P742, P747, P752, P757, P762, P767, P772, P777, P782,
P787, P792
- Sequence diagnostic/status: P561, P562
Segment #1
P710
Segment #1
Frequency
Setpoint
0.0
-500.0 {Hz} 500.0 If P112 = 1, negative sign forces
reverse direction
P711
Segment #1
Accel/Decel
Time
20.0
0.0 {sec} 3600.0
P712
Segment #1
Time in current
step
0.0
0
0.0 {P708} 6553.5
0 {P708} 65535
Scaling/units depend on P708
Skip segment if time = 0
P713
Segment #1
Digital Output
State
0
Bit0 Relay bit = 0: OFF (De-energized)
bit = 1: ON (Energized)
The corresponding digital output/
relay must be set to accept value the
from the sequencer: P140, P142=27
Bit1 TB14
P714
Segment #1
TB30
Analog Output
Value
0.00
0.00 {VDC} 10.00 TB30 conī°guration parameter must
be set to accept this value: P150
= 10
Segment #2
P715
Segment #2
Frequency
Setpoint
0.0
-500.0 {Hz} 500.0 If P112 = 1, negative sign forces
reverse direction
P716
Segment #2
Accel/Decel Time
20.0
0.0 {sec} 3600.0
P717
Segment #2
Time in current
step
0.0
0
0.0 {P708} 6553.5
0 {P708} 65535
Scaling/units depend on P708
Skip segment if time = 0
