7
Technical data
480VAC Models
Type
Power
[Hp/kW]
Mains Output Current
SM2
Watts
Loss
SM4
Watts
Loss
Voltage
(1)
I
in
I
n
CLim
max
(2)
400V 480V 400V 480V 400V 480V
174620-174671 0.5 / 0.37
400 V Three-phase (3/PE)
(340 … 440 V)
OR
480 V Three-phase (3/PE)
(340 … 528 V)
1.7 1.5 1.3 1.1 175 200 23 21
174621-174672 1 / 0.75 2.9 2.5 2.4 2.1 175 200 37 33
174622-174673 1.5 / 1.1 4.2 3.6 3.5 3.0 175 200 48 42
174623-174674 2 / 1.5 4.7 4.1 4.0 3.5 175 200 57 50
174624-174675 3 / 2.2 6.1 5.4 5.5 4.8 175 200 87 78
174625-174676 5 / 4.0 10.6 9.3 9.4 8.2 175 200 128 103
174626-174677 7.5 / 5.5 14.2 12.4 12.6 11.0 175 200 178 157
174627-174678 10 / 7.5 18.1 15.8 16.1 14.0 175 200 208 190
174628 15 / 11 27 24 24 21 155 180 418
174629 20 / 15 35 31 31 27 155 180 493
174630 25 / 18.5 44 38 39 34 155 180 645
174991 30 / 22 52 45 46 40 155 180 709
174992 40 / 30 68 59 60 52 155 180 1020
174710 50 / 37.5 85 74 75 65 155 180 1275
174711 60 / 45 100 87 88 77 155 180 1530
600 VAC Models
Type
Power
[Hp/kW]
Mains Output Current
SM2
Watts
Loss
SM4
Watts
Loss
Voltage
(1)
I
in
I
n
CLim
max
(2)
174631-174663 1 / 0.75
600 V Three-phase (3/PE)
(425 … 660 V)
2.0 1.7 200
37 31
174632-174664 2 / 1.5 3.2 2.7 200 51 43
174633-174665 3 / 2.2 4.4 3.9 200 68 57
174634-174666 5 / 4.0 6.8 6.1 200 101 67
174635-174667 7.5 / 5.5 10.2 9 200 148 116
174636-174668 10 / 7.5 12.4 11 200 172 152
174637 15 / 11 19.7 17 180 380
174638 20 / 15 25 22 180 463
174639 25 / 18.5 31 27 180 560
174993 30 / 22 36 32 180 640
174994 40 / 30 47 41 180 930
174712 50 / 37.5 59 52 180 1163
174713 60 / 45 71 62 180 1395
(1) Frequency Range: 48 Hz … 62 Hz
(2) Current Limit (CLim) is a percentage of the output current, I
n
. CLim
max
is the maximum setting for P171.
For 480VAC models, the CLim
max
value in the 480V column of the table is used when P107 is set to 1.
The CLim
max
value in the 400V column is used when P107 is set to 0.
STOP!
Drive Derating
The SM2 and SM4 Vector Series drive is designed to operate at the Nominal Output Current (I
n
)shown
in the Ratings tables for most standard applications and industrial environments. The drive output
current or operating temperature may need to be limited as described below:
For installations above 1000m a.m.s.l., derate I
n
by 5% per 1000m, do not exceed 4000m a.m.s.l.
• Operation above 40°C, derate I
n
by 2.5% per °C, do not exceed 55°C.
Carrier Frequency (P166):
- If P166=2 (8 kHz), derate I
n
to 92% of drive rating or do not exceed 33°C ambient
- If P166=3 (10 kHz), derate I
n
to 84% of drive rating or do not exceed 27°C ambient
For combinations of the above, please consult LEESON applications support for proper derating.
