LEGRAND ALPTEC 8.2 User Manual

10
CONTENTS
13  PARAMETER TABLES CONTINUED
“ADV” advanced menu
Code Description ACC UoM DEF
Range
P.21 Password enabled Adm ON
OFF
ON
P.22 User password Usr 001
0-999
P.23 Advanced password Adm ***
***
P.24 Type of connection Usr 3PH
3PH Three-phase
1PH Single-phase
P.25 Step power setting Usr ON
ON Enabled
OFF
P.26 + target cos phi tolerance Adm 00:00
0 – 0.10
P.27 - target cos phi tolerance Adm 00:00
0 – 0.10
P.28 Step insertion mode Adm STD
STD Standard
Lin Linear
Disc Disconnection
P.29 Target cos phi on cogeneration Usr OFF
OFF/
0.50 LEAD – 0.50
LAG
P.30 Sensitivity on disconnection Adm s OFF
OFF/1 – 600
P.31 Disconnection of steps in MAN mode Usr ON
OFF
ON Enabled
P.32 Capacitor overload alarm threshold Adm % 105
OFF/100...150
P.33 Capacitor overload immediate disconnection alarm
threshold
Adm % 110
OFF/100.. 200
P.34 VT primary Usr V OFF
OFF/50-50,000
P.35 VT secondary Usr V 100
50-500
P.36 Temperature UoM Usr °C
°C °Celsius
°F °Fahrenheit
P.37 Fan start-up temp. Adm ° 55
0 .. 100°C
(32...212°F)
P.38 Fan switch-o temp. Adm ° 50
0 .. 100°C
(32...212°F)
P.39 Temperature alarm threshold Adm ° 45
50 .. 100°C
(122...212°F)
P.40 Faulty step alarm threshold Adm % OFF
OFF/25…100
P.41 Overvoltage alarm threshold Adm % 107
OFF/90...150
P.42 Undervoltage alarm threshold Adm % 80
OFF/60..110
P.43 THD V alarm threshold Adm % 3
OFF/5..250
P.44 THD I alarm threshold Adm % 10
OFF/5..250
P.45 Maintenance interval Adm kh 3.76
1 - 30,000
P.46 Bar graph function Usr kVAr
inst/tot
Inst/tot kVAr
Act/nom curr
Rchd/tot kVAr delta
P.47 Default auxiliary measurements Usr kVAr
delta
kVAr delta
V
A
Weekly cos phi
Overload
Temp
THDV
THDI
ROT
P.48 Backlight enabled on alarm Usr ON OFF
ON
P.49 Serial address (unsigned) Usr 01 01-255
