11  FIRST SWITCHON

If the primary CT value needs to be set when the controller is rst switched on, parameter P.01 is set to OFF:

- The main screen then displays the code ashing.

- Use and to change the value of the primary.

- Conrm by pressing or



MANMODEA

- The controller saves the parameter value and starts up in mode .

12  MAIN PROGRAMMING ACTIONS

Changing the primary CT value

If the primary CT value needs to be modied:

- Press or



NMODEAUT

to switch to mode .

- Following the procedure outlined in the “Setting the “SET” parameters” section on page 7, go to the BAS menu, then to parameter P.01.

- Use and to change the value of the primary.

- Hold down or



MANMODEA

until the countdown starts to conrm the new value.

- Press or



MANMODEA

to switch to mode .

Setting the cos phi setpoint

- Following the procedure outlined in the “Setting the “SET” parameters” section on page 7, go to the BAS menu, then to parameter P.19.

- Press or to change the value of the cos phi.

- Press to conrm the new value.

- Press or



MANMODEA

to switch to mode .

13  PARAMETER TABLES

This is a list of all the programming parameters in tabular form. The possible setting range and factory setting are indicated for each parameter, along with a

brief explanation of the parameter function. The parameter description displayed on the screen may in some cases dier from that quoted in the table due to a

lower number of characters being available. However the parameter code can be used as a reference.

Note: The greyed-out parameters shown in the table are essential for the system to work, and therefore represent the minimum programming required for

operation.

“BAS” Basic menu

Code Description ACC UoM DEF Range

P.01 CT primary Usr A OFF OFF/1...10,000

P.02 CT secondary Usr A 5 1/5

P.03 CT read phase Usr L1

P.04 CT connection direction Usr Aut

Aut

Dir

Rev
