CÉLIANE TECHNICAL GUIDE
III-145
sCs Bus automation system
Reset
035 65
N646
SCSEthernet 12V
Auxiliary controls
Some special functions may be performed using a common
resource for all SCS systems: the auxiliary channels. Up to 9
transmission channels are available for sending controls. It is
possible to send controls through the auxiliary channels from any
devices, by configuring A=AUX and PL=1-9. The PL configurator
specifies through which auxiliary channel the control must be
sent, while the operating mode is specified by configurator M as
for all other controls.
Actuators do not directly recognise these controls; it is therefore
necessary to use the special control that translates the auxiliary
in a control that can be performed by the actuators.
Main actuator operating modes
CEN operating mode
This special operating mode can be used for managing scenario
programming devices 035 65. As outlined in this guide, the device
can be used to manage scenarios, including complex ones, that
are activated automatically following system events, or manually
by pressing the key of a control device configured with the CEN
configurator in the M position. The connection between the key
(upper or lower) of the control device and the scenario to activate,
is performed using the software for the creation of scenario,
following by saving the scenario inside the device. For example,
four independent scenarios may be activated, suing the control
device 672 41, and using pushbuttons T1-T4.
Actuators may be configured with the following operating modes:
035 65 scenario programming device
A = 1–9
PL = 1–9
M = CEN
Key T1 = Scenario1
Key T2 = Scenario2
Key T3 = Scenario3
Key T4 = Scenario4
The control device address
is specified in the A and PL
positions.
Tabella
Configurator value (M) Function performed
Special functions
This mode can be used to perform special functions (delayed OFF, timed STOPS), based on the type of actuator used (single or
double) and the numeric configurator used.
Slave
This mode can be used to instruct two or more actuators to perform the control. In practice, with the SLA (Slave) configurator, the
actuators repeat the function performed by another actuator operating as a Master.
Actuators must have the same addresses and must be of the same type (or all light actuators, or all shutter actuators)..
PUL
The device does not activate with Room and general controls
M
M
ON
M
OFF
M
O/I
M
M
M
M
M
SLA
M
SPE
1√8
1√8
PUL
1√8
M
1√4
M
configurator PUL
M
M
ON
M
OFF
M
O/I
M
M
M
M
M
SLA
M
SPE
1√8
1√8
PUL
1√8
M
1√4
M
configurator 1 - 4
M
M
ON
M
OFF
M
O/I
M
M
M
M
M
SLA
M
SPE
1√8
1√8
PUL
1√8
M
1√4
M
configurator SLA
4321
C1 C2
1 2 3 4
038 42
T1
T3
T2
T4
