be distinguished by their number, letter or graphic label or
by virtual configuration. The destination address or source
address of the control as well as the operating mode of the
device (activation/deactivation or adjustment of a load) shall
be assigned with the configuration inside the system.
In order for each SCS BUS system device to perform its
functions properly, it must be appropriately configured, thus
assigning its functioning mode and address.
This procedure, called configuration, is carried out by
inserting push-in devices, called configurators, which can
DEVICE CONFIGURATION
Introduction
to the Automation system
PHYSICAL CONFIGURATION
Numbered
configurator
Configurator
housing
Description of the
configurator housing
Tool for insertion
of configurator
The devices communicate
with each other because
they have the same
configuration
➔
Power supply
DIN actuator
INFORMATION
SCS BUS
230 Vac
➔
