Install the main distribution board in a technical room, or under
the stairs. Install another distribution board on each floor, in a
central position. DIN rail devices will be partly centralised, and
partly distributed.
MULTI FLOOR HOUSE
1 FLOOR APARTMENT
• 1, 2 or 3 rooms + bathrooms: only include one distribution
board, at a central position, where all DIN rail devices will be
installed.
•
More than 3
rooms + bathrooms
: only include one distribution
board, at a central position. DIN rail devices will be installed
partly on the board, while the rest will be distributed around the
house.
3
rd
FLOOR
2
ND
FLOOR
1
ST
FLOOR
Equipment
room
