The components must be installed at the following heights from the ground.
MINIMUM HEIGHTS RECOMMENDED HEIGHTS
90 cm
Height of handles
Fixed burglary alarm IR sensors and controls
70÷80 cm
Headboard sockets and controls
30 cm
Wall mounting sockets
(electricity, telephone, TV, data transmission)
17,5 cm
Wall mounting and wall sockets
7 cm
Sockets on conduit supports or skirting boards
4 cm
Sockets on towers, or protection shields protruding from floor
The positioning of wall boxes varies depends on the type of devices they will house (controls, IR sensors, temperature sensors,
video cameras etc.).
Positioning
of wall boxes
