Leica Disto X310 - Technical Specifications

Leica DISTO
TM
X310 788479a
17
ENTechnical Data
* applies for 100 % target reflectivity (white painted wall),
low background illumination, 25 ºC
** applies for 10 to 500 % target reflectivity, high background
illumination, - 10 ºC to + 50 ºC
*** Tolerances apply from 0.05 m to 10 m with a confidence
level of 95%. The maximum tolerance may deteriorate to
0.1 mm/m between 10 m to 30 m and to 0.20 mm/m for
distances above 30 m
**** applies for 100 % target reflectivity, background illumi-
nation of approximately 30'000 lux
***** after user calibration. Additional angle related devia-
tion of +/- 0.01° per degree up to +/-45° in each quadrant.
Applies at room temperature. For the whole operating
temperature range the maximum deviation increases by
+/-0.1°.
For accurate indirect results, the use of
a tripod is recommended. For accurate
tilt measurements a transverse tilt should be
avoided.
Distance measurement
Typical Measuring Tolerance* ± 1.0 mm / ~1/16" ***
Maximum Measuring
Tolerance**
± 2.0 mm / 0.08 in ***
Range at Leica target plate
GZM26
100 m / 330 ft
Typical Range* 0.05-80 m / 2-265 ft
Range at unfavourable
condition ****
60 m / 197 ft
Smallest unit displayed 0.1 mm / 1/32 in
Power Range Technology
™
yes
Ø laser point
at distances
6 /30 / 60 mm
(10 / 50 / 100 m)
Tilt measurement
Measuring tolerance to laser
beam*****
± 0.2°
Measuring tolerance to
housing*****
± 0.2°
Range 360°
General
Laser class 2
Laser type 635 nm, < 1 mW
Protection class IP65 (dust tight and jet
water protected)
Autom. laser switch off after 90 s
Autom. power switch-off after 180 s
Battery durability (2 x AAA) up to 5000 measure-
ments
Dimension (H x D x W) 122 x 55 x 31 mm
4.80 x 2.17 x 1.22 in
Weight (with batteries) 155 g / 4.98 oz
Temperature range:
-Storage
-Operation
-25 to 70 °C
-13 to 158 °F
-10 to 50 °C
14 to 122 °F
i
Functions
Distance measuring yes
Min/Max measuring yes
Permanent measuring yes
Stake-out yes
Addition/Subtraction yes
Area yes
Triangle area yes
Volume yes
Painter function (area with
partial measurem.)
yes
Pythagoras 3-point, partial height
Smart Horizontal Mode /
Indirect height
yes
Height tracking yes
Memory 20 displays
Beep yes
Illuminated display yes
Multifunctional endpiece yes
