Leica Disto X310 - Measurement Functions; Single Distance Measurement; Min;Max and Permanent Measurement; Add and Subtract Measurements

Leica DISTO
TM
X310 788479a
7
ENMeasuring Functions
Measuring single distance
1
Aim active laser at target.
2
8.532 m
3
i
Target surfaces: Measuring errors
can occur when measuring to col-
ourless liquids, glass, styrofoam or
semi-permeable surfaces or when
aiming at high gloss surfaces.
Against dark surfaces the measur-
ing time increases.
Permament / Minimum-Maximum measuring
1
2 sec
8.532 m
Used to measure room diagonals (maximum val-
ues) or horizontal distance (minimum values)
The minimum and maximum dis-
tance measured is displayed (min,
max.). The last value measured is
displayed in the main line.
min. max.
2
Stops permanent / minimum-
maximum measuring.
3
Add / Subtract
7.332 m
1
The next meas-
urement is added
to the previous
one.
2
The next meas-
urement is sub-
tracted from the
previous one.
7.332 m
12.847 m
3
i
The result is shown in the main
line and the measured value
above. This process can be re-
peated as required. The same
process can be used for adding or
subtracting areas or volumes.
