Leica Disto X310 - Multifunctional Endpiece Usage; Setting Distance Units; Setting Tilt Units; Automatic Release Timer

Leica DISTO
TM
X310 788479a
5
ENOperations
Multifunctional endpiece
i
The orientation
of the endpiece
is automatically
detected and
the zero point is
accordingly ad-
justed.
Distance unit setting Tilt unit setting
Switch between the
following units:
0.000 m
0.0000 m
0.00 m
0.00 ft
0‘00‘‘ 1/32
0.00 in
0 in 1/32
2 sec
Switch between the
following units:
0.0 °
0.0 %
2 sec
simultaneously
Timer (automatic release)
s
1
Adjust delay of auto-
matic release (max.
60 sec, standard set-
ting 5 sec)
2
i
Once the key is released with the la-
ser activated, the remaining seconds
until the measurement is displayed in
a countdown. The delayed release is
recommended for precise aiming
e.g. at long distances. It avoids shak-
ing of the device when pressing the
measurement key.
