Leica FlexLine - Page 20

FlexLine/FlexLine plus, 20
Peg Survey
Saving the data The following results are stored in the internal memory.
No. of Sets Number of sets.
P0 Station
P1 Backsight point
P2 Foresight point
α Avg. Hz: Averaged horizontal angle
d1 Avg. HD BS: Average horizontal
distance to the backsight point
d2 Avg. HD FS: Average horizontal
distance to the foresight point
h1 Avg. H BS: Average height of the
backsight point
h2 Avg. H FS: Average height of the
foresight point
Field Description
h1
h2
TSOX_Mining_004
d2
d1
P0
P1
P2
α
Field Description
Result
Avg. Hz Average horizontal angle between backsight point and foresight point.
Avg. HD Average horizontal distance to backsight and foresight points.
Avg. H Average height to backsight and foresight points.
