Leica FlexLine - Grade Results

FlexLine/FlexLine plus, 30
Grades
4.4 Grade Results
Description The Grades application computes the height difference (dH) between the measured
point and the stake out point, and the difference in horizontal distance (dHD) along
the foresight line.
Profile view
Top view
P0 Station
P1 Foresight point
aGradeline
dH Difference in height
dHD Difference in horizontal
distance
P0 Station
P1 Foresight point
a New gradeline point
dHD Difference in horizontal distance
TSOX_Mining_008
a
dHgt
dHD
P0
P1
TSOX Mining 009
a
dHD
P0
P1
