FlexLine/FlexLine plus, 34
Offset
5.2 Starting Offset
Access The Offset application is started by either selecting it in the Programs menu or after
measuring in the applications PegSurvey and LinePeg.
When started from the Programs menu, station data must be entered and a
measurement made to backsight and foresight points first, before the Offset
application can be used.
Starting offset
step-by-step
Step Description
1. Select Programs from the Main Menu.
2. Select Grades&Off from the Programs menu, and complete the
application pre-settings by:
• Selecting a job, and
• Confirming the set of tolerances. Refer to "1.2 Selecting Tolerance
Profiles".
3. Select Start to proceed to the Mining - Enter Station Data screen.
4. Input station data and measure to the backsight and foresight points. Refer
to "2 Peg Survey" for details on this process.
5. Accept the tolerances from the measurements.
6. In the Continue with... screen, press Offset to start the Offset
application.
