Tolerances FlexLine/FlexLine plus, 5
1 Tolerances
1.1 Defining Tolerances
Description Before use of the mining applications, tolerance profiles have to be defined and
selected. The definition of tolerances can be done either via the Mining Data Manager
software or manually on the instrument. This chapter describes defining and
selecting tolerances manually. Refer to "6 Mining Data Manager" for details on using
the Mining Data Manager software.
Access 1. Select Programs from the Main Menu.
2. Select Tolerances from the Programs menu.
3. Enter the current PIN.
4. Press Cont to proceed to the tolerance profile screen.
)
If a wrong PIN has been typed in 5 times, a Personal Unblocking code (PUK) is
required, which can be found on the instrument delivery papers. If the entered PUK
code is correct, then the PIN code is reset to default value "123456".
