Leica GR50 - Page 32

GR30/GM30/GR50, Installation
32
Tripod The instrument has a built-in Tripod mount to allow attachment to all Leica Geosys-
tems Tripods.

When using the instrument on a tripod, the rubber bumpers must be on.
a) AR10/AS10(shown)
b) GNSS antenna carrier with 5/8 inch screw
c) Tribrach
d) Tripod
e) Antenna cable
f) GR30/GM30/GR50
GR10_019
a
b
c
d
e
f
