69
Leica IP C
Cleaning and Maintenance 6
For transport or when the printer is to be disconnected from the power for long periods (from more than
24 h up to six months), a transport cartridge has to be inserted. To do so, proceed as follows:
1. (→ p. 67 – 6.3.1 Removing the used ink cartridge): Follow steps 1 to 5.
Note
The ink cartridge cannot be used in another printer, because the ink level information is stored in the
printer itself.
2. Take the (new) transport cartridge (→ "Fig. 58-1") out of the delivery carton.
3. Remove the protective foil and insert the cartridge until it is about half way into the cartridge
slot (→ "Fig. 58").
4. Loosen the red protective cap (→ "Fig. 58-2") by one turn.
5. Push in the transport cartridge all the way and check that the red retaining bracket
(→ "Fig. 57-1") is positioned correctly.
6. Unscrew the red protective cap (→ "Fig. 58-2") and place it in the recess provided for the cap
in the cartridge (→ "Fig. 58-3").
7. Mark one of the two boxes on the front of the cartridge to ensure that the transport cartridge is
used only twice.
8. Close the cover plate on the left side of the printer.
Fig. 58
1
3
2
4
9. The INK EMPTY LED goes out, and 88 appears in the display.
10. Press CLEAN to clean the print head (duration: approx. 3.5 min) - 00 appears in the display. The
display will go out when the cleaning process is complete.
