EN
125
Preparations
First aid:
If battery fluid comes into contact with the eyes, there is a risk
of blinding.
Wash the eyes thoroughly with clean water immediately. Do not
rub the eyes. Seek medical attention immediately.
If leaked fluid gets onto the skin or clothing, there is a risk of
injury. Wash the affected areas with clean water.
Notes:
The battery is supplied partially charged, but it should be
charged before long periods of use.
In order to charge the battery, it must have a temperature of
between 0°C and 35°C / 32°F and 95°F (otherwise the
charger may not turn on or off again).
Lithium ion batteries can be charged at any time, regardless of
their current charge level. If a battery is only partly discharged
when charging starts, it is charged to full capacity faster.
Lithium ion batteries should only be stored in a partially charged
condition, i.e. not fully charged or fully discharged. For very long
storage periods, batteries should be charged for around 15
minutes around twice a year to prevent total discharge.
The batteries warm up during the charging process. This is
normal and not a malfunction.
A new battery only reaches its full capacity after it has been fully
charged and – by use in the camera – discharged 2 or 3 times.
This discharge procedure should be repeated every 25 cycles.
Rechargeable lithium ion batteries generate power through
internal chemical reactions. These reactions are also influenced
by the external temperature and humidity. To ensure a maximum
service life of the battery, it should not be exposed to (high or
low) extremes of temperature (e.g. in a parked car in the
summer or winter).
Even with optimum conditions of use, every battery has a limited
service life. After several hundred charging cycles, this becomes
noticeable as the operating times get significantly shorter.
Take damaged batteries to an appropriate collection point for
proper recycling, in line with the applicable regulations (see p.
119).
The replaceable battery supplies another back-up battery that is
integrated into the camera. This back-up battery ensures that
the date and time data entered is retained for up to 2 days. If
this back-up battery becomes discharged it must be recharged
by inserting a charged main battery. Once the replaceable
battery has been inserted, the full capacity of the back-up
battery is recovered after about 60 hours. This process does not
require the camera to be turned on. However, the date and time
will need to be entered again.
Remove the battery if you will not be using the camera for a long
period of time. When doing so, turn the camera off using the
main switch first. Otherwise, after several weeks the battery
could become totally discharged, i.e. the voltage is sharply
reduced as the camera still consumes a small amount of current
(for saving your settings) even when it is turned off.

Table of Contents

Other manuals for Leica T

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Leica T and is the answer not in the manual?

Leica T Specifications

General IconGeneral
Megapixel16.3 MP
Camera typeMILC Body
Sensor typeCMOS
Sensor formatAdvanced Photo System type-C (APS-C)
Image stabilizerNo
Total megapixels16.5 MP
Image sensor size- \
Image formats supportedJPG
Supported aspect ratios3:2
Maximum image resolution4944 x 3274 pixels
Image sensor size (W x H)23.6 x 15.7 mm
Still image resolution(s)4272 x 2856, 3264 x 2160, 2144 x 1424, 1632 x 1080, 4944 x 3278
Optical zoom- x
Mounting typeBayonet
Focal length range- mm
Lens mount interfaceLeica T
Minimum aperture number-
Focus adjustmentAuto/Manual
Auto focusing (AF) modesMulti Point Auto Focus, Single Auto Focus, Spot Auto Focus
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivityAuto
Light exposure modesAperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)12500
ISO sensitivity (min)100
Light exposure controlProgram AE
Light exposure correction± 3EV (1/3EV step)
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed30 s
Flash modesAuto, Flash off, Flash on, Red-eye reduction, Slow synchronization
Flash sync-speed1/180 s
Flash guide number4.5 m
Flash recharging time5 s
Flash exposure correction±3EV (1/3 EV step)
Flash exposure compensationYes
Power source typeBattery
Video resolutions1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate30 fps
Video formats supportedMP4
Maximum video resolution1920 x 1080 pixels
Resolution at capture speed1920x1080@30fps
Memory slots1
Internal memory16 MB
Compatible memory cardsSD, SDHC, SDXC
Display diagonal3.7 \
Display resolution854 x 480 pixels
Display resolution (numeric)1300000 pixels
USB version2.0
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
White balanceCloudy, Daylight, Halogen, Shade
Self-timer delay2, 12 s
Battery typeBP-DC 13
Battery voltage7.2 V
Battery capacity985 mAh
Battery life (CIPA standard)400 shots
MaterialAluminum
Product colorSilver
Cables includedUSB
Bundled softwareAdobe Photoshop Lightroom,
Weight and Dimensions IconWeight and Dimensions
Depth33 mm
Width134 mm
Height69 mm
Weight339 g
Weight (including battery)384 g
