ADJUSTING THE FINGER ASSEMBLY
8
Chapter 2 Super Jig-12-18-24 User Guide
2-6 You can adjust the guidefingers by eye, or by measurement
to suit a set of plans.
■
2-5 Always tighten unused guidefingers before routing, as
router vibration may cause loose screws and finger lock parts to
fall out and be lost.
