JIG PARTS LIST
76
Appendix III Super Jig-12-18-24 User Guide
How to Order Parts
Order directly from Leigh by calling toll free 800-663-8932, or if you’re outside North America contact
your national distributor. Have your jig information ready — You’ll need the jig model, serial number,
part number, part description and quantity required.
Note: Place the finger assembly in half-blind mode
to determine left hand and right hand scales.
PART DESCRIPTION QUANTITY PART NO. SUPER 12 SUPER 18 SUPER 24
Super Jig Front Body Extrusion
1 8012 8018 8024
Super Jig Rear Body Extrusion
1 8112 8118 8124
Guide Fingers
see model 7200 Quantity 13 Quantity 16 Quantity 19
Guide Finger Nuts (Threaded)
see model 7210 Quantity 15 Quantity 18 Quantity 21
Guide Finger Washers
see model 7215 Quantity 15 Quantity 18 Quantity 21
Guide Finger Wedges
see model 7220 Quantity 15 Quantity 18 Quantity 21
8/32 x 6.57mm Finger Screws
see model 7225R Quantity 15 Quantity 18 Quantity 21
R.H. Inch Scale Assembly, complete (R.H. in H.B. Tail Mode)
1 7230
or R.H. Metric Scale Assembly, complete (R.H. in H.B. Tail Mode)
1 7230M
L.H. Inch Scale Assembly, complete (L.H. in H.B. Tail Mode)
1 7235
or L.H. Metric Scale Assembly, complete (L.H. in H.B. Tail Mode)
1 7235M
SJ End Housing R.H.
1 8005
SJ End Housing L.H.
1 8010
SJ Support Bracket R.H.
1 8050
SJ Support Bracket L.H.
1 8060
Scale Block R.H. (RH in HB Tail Mode)
1 7230
Scale Block L.H. (LH in HB Tail Mode)
1 7235
SJ Non-Slip Self Adhesive Strips
4 8712 8718 8724
SJ Front Side Stops
2 8160
SJ Rear Side Stops
2 8170
SJ Spacer
1 8180
Clamp Tube Extrusion - Front
1 8212 8218 8224
Clamp Tube Extrusion - Rear
1 8312 8318 8324
Clamp Tube End Plugs
4 7115
Screwdriver - No. 2 Robertson Square Drive
1 550
1" Aluminum Finger Bar
1 8412 8418 8424
Plastic Bridge Extrusions
3 8512 8518 8524
Nylon Depth Rod
1 8612 8618 8624
Support Bracket Knobs
2 7025
Clamp Bar Springs
4 311
Scale Thumb Screws
2 7250
Scale Thumb Screw Washers
2 7255
Clamp Bar T-Bolts - 5/16"-18 x 4"
4 7100
8 x 1-1/2" End Housing Screws
12 7145
5/16"-18 Hex Nuts
4 300
5/16" SAE Flat Washers
4 283
SJ Hold Down Screws #10 x 1"
4
8145
SJ User Guide
1 8200
SJ Instructional Pull Out
1 8210
Cam Clamps
4 7125
Cam Nuts 5/16"-18
4 7120
SJ Instructional DVD
1 8250
# 80-8 1/2" Dovetail Bit
1 80-8
# 140-8 5/16" Straight Bit
1 140-8
# 120-8 14º Dovetail Bit
1 120-8
1/2" to 8mm Collet Reducer
1 172-8
e7 eBush (guide Bushing) and nut
1 e7-Bush
Pin Wrench
1 730V
