ATTACHING THE LEIGH e‑Bush TO A ROUTER
68
Appendix i SuperJig-12-18-24 User Guide
Template Guide Bushing and Adaptor Selection
Leigh dovetail jigs require a router fitted with a guide bushing. An adaptor may be required to fit the bushing to the
router.
See www.leighjigs.com for the complete list of routers.
DIRECTIONS
A. Locate name of router maker in Column 1.
B. Locate router model in Column 2. If your
router is not listed visit leighjigs.com for a
complete, up-to-date list of routers.
C. Locate adaptor required for your router in
Column 3.
• Order Leigh adaptors (part no’s in red) in
Column 3 from Leigh.
• Order Bosch adaptors RA1100 and
RA1126 in Column 3 from Leigh or your
Bosch dealer.
• Order all other adaptors in Column 3 from
the router manufacturer’s dealer.
Note: Adaptor mounting screws are included
with router.
■
MAFELL – Rework adaptor slightly.
D. Guide bushings in Column 4 fit all adaptors
listed and may be ordered if required.
◆ The
e7 elliptical guide bushing (7/16"
[11,1mm]) is supplied with all Leigh
SuperJigs for routing dovetails and
box joints. Order only if you require a
replacement. The 711C/711TP* guide
bushing (7/16" [11,1mm]) can also be
used, but only for routing dovetails.
All 8mm shank bits work with the e7-Bush
supplied with your Leigh jig, or with any
7/16
"OD[11,1mm] guide bushing that has a
min. barrel length of 1/4" [6,35mm]. No other
guide bushing sizes can be used.
*
Note: The 711C has replaced the 711TP
guide bushing.
1
ROUTER
MAKER
2
ROUTER
MODEL
3
ROUTER
ADAPTOR
4
7/16" OD
BUSHING ◆
AEG
OFE 710 in plunge base Not Required
e7 or 711C
OFSE 2000 703
e7 or 711C
RT1350E 706R
e7 or 711C
BLACK & DECKER
All Professional, HD1250, RP400K, 7614 Not Required e7 or 711C
6200 720673-00 e7 or 711C
SR100, 7AEE, KW780 series, KW800, KW850 710 e7 or 711C
BOSCH
90085, 90088, 90098, 90140, 90150, 90300, 90303, 90305, 91264 Aftermarket base plate required e7 or 711C
1600, 1601, 1602, 1603, 1604, 1606, B1350
RA1110 required
e7 or 711C
North American ROUTERS PRODUCED AFTER mid-2010: 1613EVS, 1613AEVS, 1617,
1617EVS, 1618, 1618EVS, 1619EVS, MR23EVS, MRC23EVS, MRF23EVS, MRP23EVS
RA1100 & RA1126 required.
Sold only as Set RA1129.
(Set includes RA1100 and RA1126)
e7 or 711C
North American ROUTERS PRODUCED BEFORE mid-2010 and others available
worldwide that include the RA1126 adaptor: 1613(EVS)(AEVS), 1614(EVS), 1617EVS,
1618EVS, 1619EVS, B1450, GOF900(CE)(ACE), GOF1200, GOF1250(CE)(LCE),
GOF1300(CE)(ACE), GOF1600CE, GOF2000CE, GMF1400, GMF1600CE, POF800ACE,
POF1100AE, POF1200AE, POF1400ACE
RA1100 required.
Sold only as Set RA1129.
(Set includes RA1100 & RA1126)
e7 or 711C
1611, 1611EVS, 1615, 1615EVS, B1550, GOF1600, GOF1700ACE 702 e7 or 711C
CRAFTSMAN
(SEARS)
All non-plunge models Aftermarket base plate required e7 or 711C
135275070 Plunge See Skil 1823 or 1835
Other plunge models 702 e7 or 711C
MD11 Plunge & Fixed Base. MD9.5 Fixed Base Not Required e7 or 711C
DEWALT
DW610, DW616, DW618 Not Required e7 or 711C
DW613, DW615(UK) 710 e7 or 711C
DW614, DW615, DW621, DW624, DW625, DW626 N. America Only, Supplied w/router e7 or 711C
DW621K, DW622 and DW626 outside N. America 706R e7 or 711C
DW625 Type 1,2,3,5 outside N. America 702 e7 or 711C
DW624 & DW625 Type 4 outside N.America, DW625EK 702R e7 or 711C
ELU
OF15, OF15E, OF97, OF97E 706R e7 or 711C
MOF68, MOF69, MOF96, MOF96E 710 e7 or 711C
MOF131, MOF177 Type 1,2, & 3 702 e7 or 711C
MOF177 Type 4, MOF177EK 702R e7 or 711C
2720, 2721, 3328 Not Required e7 or 711C
3303, 3304 EO9600 or 761 270-00 e7 or 711C
3337, 3338, 3339 702 e7 or 711C
FEIN RT1800 Supplied w/router e7 or 711C
FESTOOL
OF1E , OF2E, OF650, OF900E ,OF1000, OF1010E 704R e7 or 711C
OF2000, OF2000E 705R e7 or 711C
OF1400 and OF2200 North America Only Supplied w/router e7 or 711C
OF1400 Outside North America 493566 e7 or 711C
OF2200 Outside North America
494627 O-Ring may be required
to keep bushing centered
e7 or 711C
FREUD FT1700(2), FT2000, FT2200, FT3000 721 e7 or 711C
HITACHI
TR8, TR12, FM8, M8, M12 Series 325211 OR 703 e7 or 711C
M12VC, KM12SC, KM12VC Not Required e7 or 711C
M12SA2, M12V2 325224 e7 or 711C
MAFELL LO65E 702 ■ e7 or 711C
MAKITA
M363, MRP090, RP1800(F), RP1801(F), RP2300(FC), RP2301(FC), 3612C Europe Qk Fit Base
721 e7 or 711C
3600, 3606, 3608, 3612, 3612B, 3612BR, 3612C N. America, 3620, 3621, RP0900,
RP900K
703 e7 or 711C
3601B 321 493-1 e7 or 711C
RP0910, RP1110C 706R e7 or 711C
RF1100, RF1101, RD1100, RD1101, RP1101 Not Required e7 or 711C
MASTERCRAFT
Please contact Leigh for assistance
METABO OF1612, OFE1812 (for all others, please contact Leigh for assistance) 704R e7 or 711C
MILWAUKEE
5615, 5616, 5619 49-54-1040
(replacement base)
e7 or 711C
5625 49-54-1026
(replacement base)
e7 or 711C
5670 Not Required e7 or 711C
PERLES OF808 Series, OFE6990 710 e7 or 711C
PORTER CABLE
(ROCKWELL)
All Not Required or Supplied w/router e7 or 711C
RIDGID R2930 (for all others, please contact Leigh for assistance) 704R e7 or 711C
RYOBI
R30, R50, R150, R151, RE155, R500, R501, R502 703 e7 or 711C
R600, R601, RE600, RE601 702 e7 or 711C
R160, R161, R162, R163K, R165, R170,
R175, RE175, R180, R180PL, R181, R185, ERT1150
706R e7 or 711C
SKIL
1823 or 1835 91803 e7 or 711C
SK1810, 1815, 1820, 1825 RAS140 e7 or 711C
All others Aftermarket base plate required e7 or 711C
TREND T3, T4, T5, T9, T10, T11–UniBase required 710 e7 or 711C
TRITON
TRC001 TGA006 or 704R e7 or 711C
JOF001, MOF001, TRA001
Accessory Kit (includes adaptor)
TGA001 or TGA150
e7 or 711C
WEGOMA OF850 Series 710 e7 or 711C
