Leigh Super12 - Chapter 13: Sliding Dovetails

Sliding Dovetails
SUPERJIG - CHAPTER 13
HB TAILS
With the Finger Assembly in
HALF-BLIND DOVETAIL TAILS (HB TAILS) mode,
install the cross-cut fence
KEEP the finger assembly in the same mode
Sliding Dovetail
slots are cut
across the board
face.
Inches Millimetres
HB TAILS
Active
Guide Surface
1
2
Sliding Dovetail tails
are cut across the board end edge
3
Inches Millimetres
Active
Guide Surface
51
